MODEL RC ACTUATOR

Overview

The Model RC is an actuator that REMOTELY CLOSES the valve on compressed gas cylinders such as chlorine, sulfur dioxide and ammonia cylinders and ton containers.

The actuator is battery-operated with an electric motor that rotates the valve stem towards the closed position for alignment, tests and remote operation. The actuator is designed to mount without interfering with cylinder mounted hardware such as chlorinators, regulators etc. No yoke modifications or additional adapters are required. The motor, gears and controls are assembled as one unit.

Capabilities

• Battery operated with automatic charger
• NO heavy or bulky signal cables
• Remote close by leak detector, panic button or other digital signals such as PLC or computer
• Easily attaches to valve
• Can be used on chlorine and sulfur dioxide 150# cylinders or ton containers
• Eliminates the need for scrubbers in certain applications per the Uniform Fire Code

MODEL RCTVR ACTUATOR

Overview

The Model RC-TVR is an actuator that REMOTELY CLOSES the valve on compressed gas containers such as chlorine and sulfur dioxide.

The actuator is battery-operated with an electric motor that rotates the valve stem towards the closed position for alignment, tests and remote operation. The actuator is designed to mount without interfering with container mounted hardware such as chlorinators, regulators etc. No yoke modifications or additional adapters are required. The motor, gears and controls are assembled as one unit.

Capabilities

• Battery operated with automatic charger
• NO heavy or bulky signal cables
• Remote close by leak detector, panic button or other digital signals such as PLC or computer
• Easily attaches to valve
• Eliminates the need for scrubbers in certain applications per the Uniform Fire Code

MODEL 2000C ACTUATOR

Overview

The Model 2000C is an actuator system that can REMOTELY OPEN & CLOSE the valves on chlorine and sulfur dioxide ton containers.

The system includes a battery operated actuator with an electric motor that rotates the valve stem towards the open or closed position for alignment, tests and remote operation. The actuator is designed to mount without interfering with or requiring yokes or additional adapters for dispensers or discharging hardware. The motor, gears and controls are assembled as one unit.

Capabilities

• Battery operated with automatic charger
• Optional integral leak detection for automatic shutdown
• Remote close by leak detector, panic button or other digital signals such as PLC or computer
• Easy to install or remove
• Can be used on chlorine and sulfur dioxide ton containers
• Eliminates the need for scrubbers in certain applications per the Uniform Fire Code

MODEL U ACTUATOR

Overview

The Model U is an actuator system that can REMOTELY OPEN & CLOSE the valve on a chlorine or sulfur dioxide 150# cylinder or ton container.

The system includes a battery operated actuator with an electric motor that rotates the valve stem towards the open or closed position for alignment, tests and remote operation. The actuator is designed to mount without interfering with or requiring yokes or additional adapters for dispensers or discharging hardware. The motor, gears and controls are assembled as one unit.

Capabilities

• Battery operated with automatic charger
• Optional integral leak detection for automatic shutdown
• Remote close by leak detector, panic button or other digital signals such as PLC or computer
• Easily attaches to valve
• Can be used on chlorine and sulfur dioxide 150# cylinders or ton containers
• Eliminates the need for scrubbers in certain applications per the Uniform Fire Code

MODEL RPB001 REMOTE PUSH BUTTON

Overview

The Model RPB001 is a mushroom push-button mounted in a polycarbonate enclosure. The package is designed to offer operators the ability to close all actuators at one time from a remote location. The enclosure switch is compatible with chlorine and sulfur dioxide containment areas. The twist to unlock normally-open switch is rated at 10 Amps at 230 VAC.
